The RB-DDA6A digital distribution amplifier is used for distributing digital audio data in AES/EBU format, repeating both the audio data and the status information of the input whilst re-normalising to standard digital audio levels. It has a single XLR-3 female AES/EBU audio input which is distributed to 6 XLR-3 male AES/EBU outputs. Applications include distributing audio from a digital mixing desk to multiple digital recorders, or feeding multiple studios with an output from a DAT machine. It can accept input sample rates in the range of 30kHz – 100kHz, and bit rates of 16, 20 and 24 bit. It can be used for standard distribution at 16 bit 44.1kHz, as well as for high quality 24 bit 96kHz recording. 1x XLR AES/EBU digital audio input.
Product Features
1x XLR AES/EBU digital audio input.
6x XLR AES/EBU digital audio outputs.
Sample rates up to 96kHz.
Typical Applications
Distribution of audio from a digital mixing desk to multiple digital recorders, or feeding multiple studios with an output from a flashcard player.
