The PC-AD2BC is a PC-AD2 full XLR & 9 pin D-type breakout cable, 30cm in length, with the following connections: 44 pin high density D-type plug (male) to: 2 x stereo analogue audio outputs on 4 x XLR plugs (male) 2 x stereo digital audio outputs on 2 x XLR plugs (male) 1 x remote I/O on 9 pin D-type plug (male) (2 x remote out, 1 x remote in) 1 x digital sync input on 1 x XLR socket (female) 2 x stereo digital audio inputs on 2 x XLR sockets (female) 2 x analogue audio mic/line inputs on 4 x XLR sockets (female). 44 pin high density D-type plug (male) to:
Product Features
2 x stereo analogue audio outputs on 4 x XLR plugs (male).
2 x stereo digital audio outputs on 2 x XLR plugs (male).
1 x remote I/O on 9 pin D-type plug (male) (2 x remote out, 1 x remote in).
1 x digital sync input on 1 x XLR socket (female).
2 x stereo digital audio inputs on 2 x XLR sockets (female).
2 x stereo analogue audio mic/line inputs on 4 x XLR sockets (female).
Typical Applications
Break-out cable for the PC-AD2 card.
Product Category
Radio Capture and Sound Cards Accessories
Technical Specifications
Physical Specification
Dimensions (Raw): 31cm Cable (L)
Dimensions (Raw): 12.2" Cable (L)
Dimensions (Boxed): 23cm (W) x 15cm (D) x 8.5cm (H)
