Now you can control up to 8 different Ultimatte 12 units at the same time via Ethernet. Smart Remote 4 features a 10.1 inch touchscreen for quickly navigating menus and adjusting settings, along with hard buttons with online and on air indicators for quickly switching between units. The file clear button automatically adjusts the most important settings to instantly give you incredible composites!
Official Technical Details
Connections
HDMI Video Outputs: 1 (1080p60)
Computer Interface: 2 x Rear USB-C 3.0 for connecting external mouse and keyboard to enable Smart Remote control, and for attaching USB-C storage devices to load still images, save/load presets and save/load archives. 1 x Front USB-C 3.0 provides all the same functionality as the rear USB-C ports, plus the ability to connect Mac or PC for software updates and configuration using the Ultimatte Setup utility. All USB-C ports support power delivery to connected devices.
Ethernet: 2 x 10/100/1000 Mbps Ethernet ports for connecting to LAN networks to control of the Ultimatte 12 and to perform software updates using the Ultimatte Setup utility.
Product Specifics
Rotary Knobs: 8 x rotary knobs for adjusting parameters.
Unit ID Buttons: 8 x buttons. Illuminated blue for active.
Unit ID LED Indicators: Illuminated green for online and red for on air.
Alt + Quick Load/Save Buttons: Alt button plus 5 buttons for saving presets.
Quick Load/Save Buttons: 5 x buttons for loading presets.
File Clear Button: 1 x button for Auto Key.
Alt + File Clear: Alt button plus file clear button for Auto Key using some user defined presets.
Customizable Menus: 4 x menus for building your own menu with your most used controls.
LED Control: User adjustable brightness control for LEDs.
Software
Software Updates: Software updates via USB or Ethernet connection using Ultimatte Setup utility.
Control
Touchscreen: 10.1 inch 1280 x 800 colour display panel. Integrated capacitive touchscreen with onscreen controls for settings and navigating menus.
Operating Systems
Mac 15.0 Sequoia, Mac 26.0 Tahoe or later.
Windows 11
Power Requirements
Power Supply: 1 x Locking 5.5mm barrel +12V DC power input for external power supply or battery use.
Power Usage: 24W max
Physical Installation
Adjustable desk mounting option. Rack mount ears included for installing the Smart Remote into a 19 inch rack.
Environmental Specifications
Operating Temperature: 0° to 40°C (32° to 104°F)
Storage Temperature: -20° to 60° C (-4° to 140° F)
Relative Humidity: 0% to 90% non-condensing.
What's Included
Ultimatte Smart Remote 4 G2 Universal 36W external power supply with locking connector and international adapters Welcome wallet with QR code for software download
