The CM-AESB3 is a passive “one-to-three” splitter housed in a small but robust aluminium box. It is designed to split a single AES3ID digital audio source to up to three destinations, using female BNC connectors Particularly useful in a video production and broadcast environment, the CM-AESB3 splits the input signal through high quality transformers. 75Ω termination can be applied, if desired, to unconnected outputs to maintain optimum carrier parameters. The CM-AESB3 requires no power to operate, ensuring your audio remains connected from source to destination(s) without interruption from power failures. Switchable 110Ω termination for unconnected outputs.
Product Features
1x AES3ID input (BNC).
3x AES3ID outputs (BNC).
No power needed.
Switchable 110Ω termination for unconnected outputs.
Transformer based solution provides reliability.
Typical Applications
Distribution of AES3 source to 3 mixing consoles.
Product Category
Passive Splitters
Technical Specifications
CM-AESB3: Cable Drive Capability
Cumulative cable drive capability of 100m of 75Ω coaxial cable at sample rates up to and including 96kHz.
Connections
Inputs: 1 x BNC female
Outputs: 3 x BNC female
Equipment Type
CM-AESB3: 3 Way passive AES3ID splitter with BNC connectors
Physical Specification
Dimensions (Raw): 7.7cm (W) x 8.3cm (D) x 4.2cm (H)
Dimensions (Raw): 3.0” (W) x 3.3” (D) x 1.7” (H)
Dimensions (Boxed): 22.9cm (W) x 12.7cm (D) x 7.6cm (H)
Dimensions (Boxed): 9.0” (W) x 5.0” (D) x 3.0” (H)
