The perfect way to de‑embed audio from any SDI source in SD and HD formats up to 1080p60! Audio is output on ¼" connectors for balanced analog and AES/EBU audio output to equipment such as mixers, analog decks, audio monitors and more. Mini Converter SDI to Audio is the ideal SD/HD SDI audio de‑embedder for when you don’t need the cost of the Ultra HD model!
Official Technical Details
Connections
SDI Video Inputs: 1 x SD, HD or 3G‑SDI. 1 x ALT SDI Input for automatic switch over if main input fails.
SDI Video Outputs: 1 x SDI Loop Output.
Analog Audio Outputs: 4 channels of professional balanced analog audio.
Digital Audio Outputs: 8 channels of professional balanced AES/EBU audio.
SDI Redundant Inputs: Automatically switches over if main SDI input is lost.
Multi Rate Support: Auto detection of SD, HD or 3G‑SDI.
Updates and Configuration: Via USB 2.0 high speed. (480 Mb/s)
