The perfect way to convert from SD and HD‑SDI to analog component, s‑video or NTSC/PAL composite. Mini Converter SDI to analog supports all SD and HD input formats up to 1080p30 and includes a down converter for when you need to convert from HD to standard definition analog formats such as s‑video and composite. Audio can be de‑embedded to balanced analog or AES/EBU. Mini Converter SDI to Analog is ideal for converting to older analog equipment when you don’t need the extra cost of the 6G‑SDI 4K model.
Official Technical Details
Connections
SDI Video Inputs: 1 x SD, HD or 1.5G‑SDI. 1 x ALT SDI Input for automatic switch over if main input fails.
SDI Video Outputs: 1 x SDI Loop Output.
SDI Rates: 270Mb, 1.5G
Analog Video Outputs: NTSC, PAL, S‑Video and component SD/HD from 1.5G‑SDI input.
Analog Audio Outputs: 2 channels of professional balanced analog audio with standard 1/4 inch jack connections.
Digital Audio Outputs: 2 channels of balanced AES/EBU audio.
SDI Redundant Input: Automatically switches over if main SDI input is lost.
Multi Rate Support: Auto detection of SD, HD or 1.5G‑SDI.
Updates and Configuration: USB
Reclocking: Yes
Standards
SD Video Standards: 525i59.94 NTSC, 625i50 PAL
HD Video Standards: 720p50, 720p59.94, 720p60, 1080p23.98, 1080p24, 1080p25, 1080p29.97, 1080p30, 1080PsF23.98, 1080PsF24, 1080PsF25, 1080PsF29.97, 1080PsF30, 1080i50, 1080i59.94, 1080i60
