Teradek Link AX No Mount

Name: Teradek Link AX No Mount
Brand: Teradek
SKU: TE-10-0065
Price: 618.63 EUR
Availability: InStock

€618,63 be PVM

Išpardavimas Išparduota

Siuntimo išlaidos ir mokesčiai apskaičiuojami atsiskaitant.

Link AX expands your production networking capabilities with a ruggedized, set-ready aluminum chassis wrapped around a Wi-Fi 6 (802.11AX) router. Use Link AX for multiple workflow scenarios: more cameras and devices on your local production streaming network, camera-to-cloud for multiple cameras; simultaneous camera-control over multiple cameras.

Read the Link AX blog for an in-depth breakdown of real-world workflows.

Rugged Design

Robust Aluminum Chassis
Gold-Mount and V-Mount Battery Plate Options
⅜” and ¼”-20 Mounting Points
5 customizable ethernet ports
USB-A for cellular modems like Node II with Teradek Data

Built for Production

Wi-Fi monitoring with multiple Serv devices*
20 independent viewers using Teradek TV app on mobile devices*
Add an internet connection to enable remote monitoring or camera-to-cloud workflows
Simultaneous control of multiple cameras over Wi-Fi

*Serv Micro, Serv 4K, or Serv Pro required for Wi-Fi monitoring. Sold separately.

Technical Specifications

Physical

Dimensions: 7.3” W x 5.7” D x 2” H [185mm x 145mm x 51mm]
Weight: Without battery plate: 37oz (1046g) With battery plate: 38.4oz (1090g)
Construction: Milled Aluminum
Mountability: 2x 1/4”-20 threaded holes, 1x 3/4”-16 threaded hole

Interfaces

Configuration Interfaces: Feature rich web UI for configuration nd control
Switches: On/Off, Reset, and Reboot switches
Status LEDs: Multiple LEDs for device, wireless, and network statuses

Network

Ethernet: 4x 1Gbps Ethernet Ports 1x 2.5Gbps Ethernet Port
USB: USB 2.0
WiFI: 2x2 2.4GHz MU-MIMO OFDMA 802.11 b/g/n/ax, max 20dBm per chain 2x2 5GHz MU-MIMO OFDMA 802.11 a/n/ac/ax, max 20dBm per chain Frequency Range 2.412~2.472GHz, 5.180~5.825GHz
Encryption: 802.11AX, 802.1x, 802.11i, WPA2, WPA and WEP 64/128 TKIP 128bit AES
