SWIT PL-S150D | 150W super-bright Soft Panel LED Light, 5500Lux, V-Mount, DMX, also ideal for 4K shooting, SWIT Free Design for Lighting Studios

5500Lux @ 1m high intensity, Smooth Exponential dimming curve, CRI 97 TLCI 99 SSI 73

150W Bi-color Studio SMD LED Light

Official Features

150W Ultra Bright Panel Light

PL-S150D is a 2:1 size 150W Bi-color SMD LED panel light with high intensity, smooth dimmer curve, high CRI/TLCI/SSI, for both broadcast studio and field setup.

5500Lux@1m Super Bright

PL-S150D provides 150W light output and as high as 5500Lux at 1 meter illuminance, twice brighter than regular 100W LED panels with the same size, works perfectly in broadcast studio setup especially the large 4K studios that request brighter panel lights comparing to HD studios, to reproduce more HDR details.

Exponential Dimming Curve

To produce smooth light output when dimming at low intensity range, PL-S150D provides a non-linear exponential dimming curver, and the 1% dimmer equals to only 0.3% of the full intensity, to match with the sensitivity of human eyes.

IEC 62471 Photobiological Safe Certificated

The light has been tested and certificated as “Exempt - No Photobiological Hazard” by the IEC 62471:2008 standard, without the risk of ultraviolet radiation, high energy blue light, flicking. In specific locations such as churches, museums, and ancient buildings, using this lighting fixture can effectively prevent the fading and peeling of mural artifacts, thereby protecting cultural heritage.

No Fan, No Noise

The active cooling system of PL-S150D ensures 150W high bright output with no fan or louver, to provide a silent video production environment.

2700K-6500K Continuously Adjustment

PL-S150D consists of 150W of 2700K LED and 150W of 6500K LED, and outputs 150W power at any color temperature from 2700K to 6500K.

CRI 97; TLCI 99

PL-S150D adopts high end surface mounted LEDs with super high Color Rendering Index (CRI) Ra 97, and Television Lighting Consistency Index (TLCI) 99. Objects will keep their original colors exactly under the light.

SSI 73 (D55)

SSI (Academy Spectral Similarity Index) is an evaluation of light color rendering in 4K broadcast studios, by comparing the spectral power distributions of a test light fixture with a reference light source. PL-S150D CIE D55 (comparing with sunlight) SSI scores 73, a high score to the LED light.
