2:1 size, 10000Lux@1m ultra bright, 2700-6500K, DMX, CRI 97 TLCI 99, True1 AC IN & OUT
300W Bi-color Studio SMD Panel LED Light
Official Features
300W Soft Ultra Bright Studio Panel
PL-S300D is a 300W 2:1 Bi-color SMD-LED soft light, 10,000Lux @ 1m high intensity and half-peak 64° wide beam angle for large scale broadcast studios, film sets, and event stage lighting.
10,000Lux @ 1m High Bright and Soft
The 300W soft light produces high illuminace of 10,000Lux @1m, 63° half-peak, applied for head light, key light, and background light in large-scale studios, comference hall, etc.
IEC 62471 Photobiological Safe Certificated
The light has been tested and certificated as “Exempt - No Photobiological Hazard” by the IEC 62471:2008 standard, without the risk of ultraviolet radiation, high energy blue light, flicking. In specific locations such as churches, museums, and ancient buildings, using this lighting fixture can effectively prevent the fading and peeling of mural artifacts, thereby protecting cultural heritage.
2700K-6500K Continuously Adjust
PL-S300D consists of 300W 2700K LEDs and 300W 6500K LEDs, and can be continuously adjusted between 2700K and 6500K, and output 300W power at any color temperature.
No Fan, No Noise
With SWIT's unique heat dissipation design, this high-power studio light utilizes passive cooling structure, can be full-power operated without the need for fans, ensuring zero noise in the studio environment.
Accurate Color Render
CRI 96; TLCI 99; SSI(D55) 75 These high color rendering indexes ensure that objects illuminated by the light retain their true colors, both to the human eye and in camera lenses.
Dimming Curves Selection
PL-S300H offers 4 dimming curves: linear, exponential, logarithmic, and S-curve for selection, enabling precise and smooth dimming control.
DMX, AC / DC Interfaces
PL-S300D provides 5-pin XLR DMX512 in & out, and supports USB-A 5V out to power wireless DMX receiver. The light provides PowerCON True1 AC in and loop out for up to 7 units serial connection in the studio project, and also support 3-pin XLR DC48V power input for field application.
Official Product Data
-
Model SPU: PL-S300D
-
Division: Lighting
-
Big Category: Lighting
-
Small Category: Panel Light
-
Power: 300W
-
Weight (kg): 13.8
-
Spec 1: Hardlight, DMX
-
Lifecycle: 2024New
-
Accessory Options: LA-GS150, LA-BX300, PA-LC20, LA-POS150
