Marshall CV374 Compact UHD Camera NDI HX3 and HDMI
Marshall CV374 Compact UHD Camera NDI HX3 and HDMI
The CV374 Compact 4K cameras contain a next generation Sony UHD sensor with larger pixels and up to Ultra-HD at 60 frames per second. These unique streaming cameras with easy AV over IP capability capable of a variety of streaming codecs and resolutions of up to 3840x2160p60 (progressive), 1920x1080p60, 1920x1080i60 (interlaced) and 1280x720p60. These cameras are designed with the same flexible features as other Marshall POV’s with flexible swappable lenses, remote setting control, discreet durable bodies made of lightweight aluminum alloy with rear I/O protection wings.
Overview
NDI HX3 Premium, Efficient, Low Latency, Loss-less Streaming Codec Featuring the extremely efficient NDI HX3 codecs gives the compact CV374 camera a unique advantage over other streaming cameras with 100ms end-to-end of latency using less bandwidth and maintaining the premium video quality of the source. Simultaneous HDMI output and other streaming options such as SRT, RTSP, RTMP, HEVC and more. Flexible Interchangeable CS/C Mount Lenses Marshall CV374 compact cameras are built with a CS/C lens mount with optional DC Auto Iris. Marshall offers a wide selection of high-quality CS and C mount prime and varifocal lenses to meet the individual needs of the production, project, or application. CV374 are perfectly setup for longer throws and telephoto lenses. Durable, Flexible, Powerful The compact CV374 body is chiseled from a block of aluminum alloy making it extremely durable in a discreet compact size with rear I/O protection. CV374 operates with exceptional low-light sensitivity, ensuring a clear picture in challenging lighting conditions with refined remote adjust & match capability over network or Visca over IP commands. Suitable for a variety of AV over IP network, cloud production, remote contribution, and HDMI workflows. Broadcast Performance Marshall Camera Division continues to develop camera products to follow the heritage of Marshall broadcast quality incorporating reliability, durability, flexibility and most importantly affordability with feature sets that matter to our industry partners. 8.46 Megapixel 1/2.8" Sony UHD solid-state image sensor Flexible interchangeable CS & C lens mount - lens sold separately 3840x2160p, 1920x1080p, 1920x1080i & 1280x720p resolutions available Framerates: 60, 59.94, 50, 30, 29.97, 25, 24, 23.98fps HDMI + network support for NDI HX3, RTSP, RTMP, SRT with H.264 and HEVC streaming codecs One-cable to camera option for power (PoE), video, audio, and remote setting control Audio Line input does not provide power to the audio device. Mic will use Mic Bias 1.7V and up to 3mA max current Remote adjust & match via Visca over IP, NDI|Tools, and camera control webpage PoE over Cat cable or 12V power with included power supply Applications: The compact CV374 is suitable for use in AV over IP or HDMI workflows where image quality and versatility are of utmost concern, including live broadcast, productions, concerts, courtroom
Official Specifications
- Part No.: Mount Type Megapixel Rating Focal Length Horizontal AOV Iris F-Stop M.O.D.
- CS1150-8MP: CS Mount 8MP 11~50mm 45°~10°approx DC Auto (4 pin) F1.4~close 0.8m
- CS-3816-8MP-V2: CS 8MP 3.8~16mm 68°~18° (1/2.8") DC (4 pin) F1.4 (W) ~ 1.6 (T) 0.5m~∞
- C1670-8MP: C Mount 8MP 16~70mm 30°~7°approx DC Auto (4 pin) F1.4~close 0.8m
- VS-M2812-4MP: CS 4MP 2.8mm~12mm 115°~32° DC Auto (4pin) F1.4 0.3m
- V-555.0-5MP-VIS-IR 1/2: 5MP 5.0mm 63° (1/3"), 75.5° (1/2.5"), 98° (1/1.7") F2.0 0.8m - ∞
- V-557.6-5MP-VIS-IR 1/2: 5MP 7.6mm 40.4° (1/3"), 48° (1/2.5"), 60° (1/1.7") F2.0 1.5m - ∞
Official Product Data
- Model: CV374
- Category: Compact Cameras
- UPC: 801813232516
- HS Code: 8525.89.0000
- Price: 970.00 EUR ex VAT
