The Marshall CV355-27X-IP HD60 27x with IP (HEVC) & 3GSDI captures crisp HD images up to 1920x1080p video up to 60fps from an 8.5 MP sensor with 27x optical zoom and simultaneous 3G/HD-SDI, HDMI, and IP networked H.265/H.264 interface.
Overview
27X Optical Zoom The 27X optical zoom block offers an extensive zoom range from 5.56mm to 150mm starting at 60° all the way out to 3.2° horizontal angle-of-view for maintaining image crispness from ultra-wide to long telephoto shots. IP (HEVC/SRT) Workflow SRT stands for Secure Reliable Transport. SRT is an open-source video transport protocol and technology stack that optimizes video streaming performance across unpredictable networks. With secure streams and simplified firewall traversal, SRT delivers the best quality video over the worst networks. Low-light Sensitivity The CV355-27X-IP operates with exceptional low-light sensitivity, ensuring a clear picture in variable and challenging lighting conditions, including live events, houses of worship, indoor or outdoor sporting events, and other dynamic lighting environments. IP (HEVC) Convenience One cable to camera provides up to HD video, audio, control, and power (PoE) over one cable with IP (HEVC) and HDMI simultaneous outputs with stereo audio embedding. 8.5 Megapixel (1/2.5") HD sensor 27X Optical Zoom (5.5~150mm) - 60° AOV Supports:1092x1080p and 720p 60/59.94/50/30/29.97/25 fps, 1920x1080i 60/59.94/50 fps IP formats: SRT, DHCP, DNS, HTTP, HTTPS, IPv4, NTP, RTSP, RTCP, RTP, TCP, UDP IP (HEVC/SRT) and HDMI simultaneous outputs Ethernet I/O supports video, control, audio and PoE over a single cable RS232 and 3.5mm audio input with passthrough CV355-27X-IP Applications: The CV355-27X-IP is suitable for use in networked HD and workflows where image quality and versatility are of utmost concern, including live broadcast productions, courtroom capture, corporate video, government assembly, sportscast, newscast, reality television, concerts, house of worship and many more.
Official Specifications
-
Sensor: IMX317
-
Optical Zoom: 27x
-
Digital Zoom: 12x
-
Angle of view (H): 60°
-
Vertical Viewing Angle: 35°
-
Diagonal Viewing Angle: 68°
-
Aperture: F1.66~F4.98
-
Focal Length: f=5.56mm~150.29mm
-
Focus Distance: Wide：1m ~ ∞ / Tele：1.5m ~ ∞
-
Field of View: Wide Horizontal viewing angle=60° (+/-5%) Tele Horizontal viewing angle=3.2° (+/-5%)
-
Minimum Environmental illumination: 10 lux
-
Minimum illumination: 0.1 lux (F1.6, 50IRE, 30fps)
-
Stream: Dual Stream (Main/Sub) / Webpage
-
Streaming Protocol: RTSP / RTMP / RTMPS / SRT
-
Video Compression: HEVC (H.265) / AVC (H.264) / MJPEG
-
Audio Compression: G.711 / AAC
-
Preset: 256
-
Preset Speed: NA
-
Focus System: Auto/ One-Push AF / Manual
-
Electronic shutter: 1/1 to 1/10000 sec
-
Exposure Control: Auto / Shutter Pri / Iris Pri / Manual
-
Gain Control: Auto, Manual
-
Brightness control: Yes
-
3D NR: Yes
-
WDR: Yes
-
Backlight Compensation: Yes
-
White Balance: Auto, Manual R/B Gain
-
Flip / Mirror: Yes
-
Firmware Update: Operation on Webpage
-
HDMI: 1080p : 60 / 59.94 / 50 / 30 / 29.97 / 25 fps 1080i : 60 / 59.94 / 50 fps 720p : 60 / 59.94 / 50 / 30 / 29.97 / 25 fps
Official Product Data
-
Model: CV355-27X-IP
-
Category: Zoom Block Cameras
-
UPC: 801813194029
-
HS Code: 8525.89.0000
