Marshall CV346 Compact HD Camera (3GSDI & HDMI)
Marshall CV346 Compact HD Camera (3GSDI & HDMI)
The Marshall CV346 Compact Full-HD Camera offers crisp Full-HD video with selectable framerates up to 1920x1080/720 at 60fps in both progressive and interlace formats. The CV346 features a 1/2.86” 2.5MP HD sensor, versatile CS/C lens mount with auto-iris, and remote controllability for seamless matching with other cameras in the workflow.
Overview
HDMI & 3G/HDSDI output 2.5 Megapixel (1/2.8") sensor (4:2:2 color) Interchangeable CS/C lens mount (sold separately) Full-HD resolutions: 1920 x 1080p, 1920 x 1080i, and 1280 x 720p Frame rates: 60, 59.94, 50, 30, 29.97, 25, 24, 23.98 fps Remote adjust through RS485 (Visca) or OSD menu joystick Audio Line input does not provide power to the audio device. Mic will use Mic Bias 1.7V and up to 3mA max current Wide range of picture adjustment settings including paint (red/blue), white balance, gain control, pedestal (blacks), white clip, exposure, gamma, and more Includes 12v power supply, can operate 12V+/-10% with a 6 watt draw CV346 camera rear view The Marshall CV346 Full-HD Miniature Camera offers performance, flexibility, and value in a compact form factor. Built around a next generation 2.5-Megapixel, 1/2.8-inch sensor, the CV346 delivers ultra-crisp, clear progressive Full-HD video up to 1920x1080p at 60/59/50fps and interlaced 1920x1080i at 60/59/50fps. The CV346 utilizes a full-sized HDMI and BNC (3G/HDSDI) output on rear panel and locking I/O connection for power, control, and stereo audio input (embedded on HDMI & 3G/HDSDI outputs). The CV346's CS lens mount offers a wide range of prime and varifocal lens options from ultra-wide to telephoto. The CV346 can capture detailed shots while maintaining an ultra-discreet compact point-of-view perspective without sacrificing versatility or convenience. Remote adjustment and picture settings commands are delivered via common RS485 (Visca) or OSD menu joystick on locking breakout cable. A wide range of picture adjustment settings are available and adjustable from a distance including paint (red/blue), white balance, exposure, gain control, pedestal (blacks), white clip, gamma, and more. Hirose Breakout Cable (included with camera) 1. RS-485 wire (+/-) Input 2. 12V Power 2.1 mm Plug (Center Contact) 3. Hirose connector plugs into camera 4. OSD Menu Control 5. TRS Audio Mic/Line-level input CV346 applications: The CV346 is suitable for use in HDMI Pro AV workflows or HDSDI environments including live broadcast productions, courtroom capture, corporate video, government assembly, sportscast, newscast, reality television, concerts, house of worship and many more.
Official Product Data
- Model: CV346
- Category: Compact Cameras
- UPC: 801813194173
- HS Code: 8525.89.0000
- Price: 445.00 EUR ex VAT
