Stunning Full HD resolution
The PTC-140 features 1/2.8 inch CMOS sensor, 1920x1080px Full HD resolution, 60fps.
20x Optical Zoom, 10x Digital Zoom
The PTC-140's 20x optical zoom and 10x digital zoom allows you to mount it near or far and still get great, sharp shots.
Advanced 2D/3D noise reduction function
Supports advanced digital noise reduction, even in less-than-perfect lighting conditions can shoot clear and smooth image.
H.264/H.265 video compression for streaming
With built-in streaming encoder, can encode up to 2 simultaneous streams to any cloud service.
Simple multi-camera control at your fingertips
With its ergonomic joystick and tactile button layout, the RMC-180 makes it easy to set up and control up to four Datavideo PTC-140 cameras for any live video production.
Remote control and preview by web user interface
The web user interface provides preview, pan-tilt-zoom control and configurations setting in IP mode.
RMC-300C can control up to 24 PTC-140 cameras
Works together with an iPad or Android tablet to control up to 24 Datavideo PTC-140 cameras.
In the box
1 x PTC-140 Unit
1 x IR remote controller
1 x Ceiling mount bracket-A
1 x Ceiling mount bracket -B
6 x Ceiling mount bracket screw M3*4mm
1 x UV Filter
1 x DC 12V Power Adaptor
1 x Power Cord
1 x A braided safety cable
1 x RS-232 DB9 9 Pin to 8 Pin Mini DIN Cable
1 x RS-485 2 Pin Connector
Technical Specifications
Connections: USB-C (3.0), HDMI output (Type D)
Dimensions (W x H x D) (mm): 184 x 186 x 156 mm
Weight: 1600
Tripod Mount Type: 1/4-20 UNC
Outputs: HDMI x 1, SDI x 1
Working Temperature: 0~40 °C
Image Sensor: 1/2.8 inch high quality HD CMOS sensor
Effective Pixels (Approx.): 2.07 Mega pixels
S/N Ratio: >55dB
Min. Illumination: 0.5Lux (F1.8, AGC ON)
Electronic Shutter: Auto / Manual
Zoom Ratio: 20x Optical Zoom, 10x Digital Zoom
Gamma Control: Off / Normal
Iris Control: Auto / Manual
Digital Noise Reductions: Yes
On-Screen Display (OSD): English, Simplified Chinese
White Balance: Auto, Manual, One Push, 3000K, 4000K, 5000K, 6500K
