Blackmagic URSA Mini Recorder lets you record Blackmagic RAW files onto 2.5 inch NVMe based 7mm U.2 SSD’s or standard 2.5 inch SSD Media with your URSA Mini Pro 12K! That means you can use commonly available and inexpensive high capacity solid state media! The NVMe based SSD media can record full resolution 12K, 8K and 4K 12‑bit RAW files plus it comes in much larger sizes so you can record longer without having to change disks!
Official Technical Details
Connections
Computer Interface: 1 x USB Type-C 3.1 Gen 2 with locking screw for bidirectional data link with URSA Mini Pro 12K and software updates.
Media
Media: 1 x 2.5 inch SSD for 4K, 8K and 12K recording.
Supported Codecs
Blackmagic RAW Constant Bitrate 5:1 Blackmagic RAW Constant Bitrate 8:1 Blackmagic RAW Constant Bitrate 12:1 Blackmagic RAW Constant Bitrate 18:1 Blackmagic RAW Constant Quality Q0 Blackmagic RAW Constant Quality Q1 Blackmagic RAW Constant Quality Q3 Blackmagic RAW Constant Quality Q5
Operating Systems
Mac 13.0 Ventura, Mac 14.0 Sonoma or later.
Windows 10 and 11.
Power Requirements
Power Connection: 12-pin Molex connector with passthrough to battery plate.
EMC Certifications
FCC, CE and KCC.
Environmental Specifications
Operating Temperature: 0° to 40° C (32° to 104° F)
Storage Temperature: -20° to 45° C (-4° to 113° F)
Relative Humidity: 0% to 90% non-condensing
What's Included
Blackmagic URSA Mini Recorder URSA Mini SSD Recorder Mount Plate with mounting screws USB Type-C SuperSpeed+ Cable with locking screw connectors
