Blackmagic Media Dock accelerates your post production workflow by enabling high speed network sharing and upload from up to 3 Blackmagic Media Modules from Blackmagic URSA Cine cameras. 4 x 10G Ethernet ports allow 4 separate edit stations to connect and edit directly. Blackmagic Media dock also has Ethernet over USB-C, dual AC power inputs for redundancy and an HDMI output for live monitoring of media in real time on a TV or monitor.
Official Technical Details
Connections
Interface: 3 x removable and hot-swappable Blackmagic Media Modules.
10G Ethernet Ports: 4 x 10G BASE-T
USB-C Port: 1 x USB 3.0 (up to 5Gb/s). Supports Ethernet Over USB
HDMI Monitor Outputs: 1
Computer Interface: USB-C or Ethernet for shared file access, configuration and software updates.
File Sharing Protocol
Protocol: NFS (HFS+ formatted disks only) SMB
Computer Connections: 50 max.
Storage
Storage Type: Up to 3 Blackmagic Media Modules.
External Storage Format: Blackmagic (formatted in camera)
Displays
HDMI Monitor Out Standards: 1080p50, 1080p59.94, 1080p60
Monitor Out Displays: Device Name, storage capacity and use, Cloud Sync status, User Activity, Hardware Status, storage map, network data rate graph.
Status Indicator: LED bezel indicator lights around media module bays.
Device Control
External Control: USB-C or Ethernet for configuration and software updates.
Software
Software Included: Blackmagic Cloud Setup Utility Blackmagic Proxy Generator Lite Internal software upgrade via Blackmagic Cloud Setup using USB-C port
Operating Systems
Mac 15.0 Sequoia, Mac 26.0 Tahoe or later.
Windows 10, 64-bit. Windows 11.
Power Requirements
Power Supply: Internal 100 - 240V AC 50/60Hz with IEC C14 mains input.
Power Usage: 95 W
Physical Installation
2 rack units.
Environmental Specifications
Operating Temperature: 0° to 40° C (32°to 104° F)
Storage Temperature: -20° to 60° C (-4° to 140° F)
