Blackmagic Camera ProDock
€255,00
Kaina su nuolaida
€255,00
Įprasta kaina
Blackmagic Camera ProDock transforms your iPhone into a professional production camera with all the connections you need to build a custom rig. It also supports the Blackmagic Camera app for iPhone! You get connections for HDMI monitoring, mic, headphones, genlock, USB for external disks and power! With professional BNC connections, Blackmagic Camera ProDock supports external genlock and timecode to keep all your cameras in perfect sync. You get 3 USB-C ports so you can connect control accessories and external SSDs for recording, plus the power management will ensure everything can run at the same time.
Official Technical Details
Connections
- HDMI Video Outputs: 1 x HDMI 2.1 (Type A) Outputs resolution and frame rate set in Blackmagic Camera for iOS.
- Audio Inputs: 1 x 3.5mm stereo mini-jack.
- Audio Outputs: 1 x 3.5mm stereo mini-jack.
- Timecode Input: 1 x BNC, 1 x 3.5mm audio input supports timecode in.
- Genlock Input: 1 x BNC, Tri-Sync or Black Burst. Genlock supported on iPhone 17 Pro and iPhone 17 Pro Max.
- USB-C Ports: 2 x USB 3.2 high speed ports for recording to external media 1 x USB 2.0 port for accessories
- Power: +12V to +15V DC input with locking 5.5mm barrel connector.
- iPhone Connection: 1 x USB-C cable and plug.
Audio
- Microphone: Connect external microphones via the 3.5mm stereo mini-jack, or USB‑C ports.
- Monitor: Connect headphones via the 3.5mm stereo mini-jack audio output.
Media
- Media: Record Blackmagic Camera clips to internal iPhone storage or external storage connected by USB.
Display
- Status Indicator: 1 x power LED indicator, 1 x front tally LED indicator, 1 x genlock LED indicator.
Software
- Blackmagic Camera for iOS: Download for free on the App Store.
Operating System
- Supported on iPhones running iOS 26 or later.
Power
- Power Supply: 1 x External 12V DC 60W power supply.
- Power Inputs: +12V to +15V DC input with locking 5.5mm barrel connector.
- Power Outputs: 5V 𝌂 1.5A 7.5W max output each USB‑C port.
Environmental Specifications
- Operating Temperature: 0°to 40°C (32° to 104°F)
- Storage Temperature: -20°to 45°C (-4° to 113°F)
- Relative Humidity: 0% to 90% non-condensing
What's Included
- Blackmagic Camera ProDock
- 1/4 inch to 1/4 inch mounting adapter
- External 12V DC power supply with locking connector and international socket adapters
- Welcome wallet with QR code for software download
Warranty
- Product Warranty: 1 Year Limited Manufacturer’s Warranty.
