The ATEM Micro Panel is a fantastic hardware panel for physical switching while using ATEM Software Control. It features the same professional panel design as ATEM Advanced Panels with high end backlit buttons and a low profile manual transition fader that keeps the ATEM Micro Panel incredibly portable. There are two rows of ten buttons for program and preview with a shift button to access up to 20 sources. Plus, buttons for upstream and downstream keyers, transitions, preview transition, macros and the four M/E buttons mean it can work with the biggest switchers. Connect ATEM Micro Panel to the ATEM Software Control computer by USB-C or the big internal battery allows wireless connection by Bluetooth for hours!
Official Technical Details
Connections
Computer Interface: USB Type‑C.
Bluetooth: Bluetooth 5.1 LE
Product Specifics
Number of Mix Effects Rows: 1
Direct Cross Points: 10
Shifted Cross Points: 20
Crosspoint Button Type: Tri-Color LED
Preview Transition: 1
Switching Type Buttons: CUT and AUTO
Transition Type Buttons: DIP, DVE, STINGER, MIX, WIPE.
M/E Select Buttons: 4
Upstream Key Buttons: 4 with ON/OFF
Downstream Key Buttons: 2 with ON/OFF
Transition Slider: 1
Software
Software Applications: ATEM Micro Panel controls ATEM Software Control Panel running on the host computer.
Operating Systems
Mac 14.0 Sonoma, Mac 15.0 Sequoia or later.
Windows 10 and 11.
Power Requirements
Power Supply: Internal battery with power switch. USB-C port for external power supply and battery charging.
Power Usage: 3 W max.
Battery Life: Minimum 6 hours. (under normal use)
Environmental Specifications
Operating Temperature: 5° to 40° C (41° to 104° F)
Storage Temperature: -20° to 45° C (-4° to 113° F)
Relative Humidity: 0% to 90% non‑condensing
What's Included
ATEM Micro Panel Welcome wallet with QR code for software download
