SSD Interface
4 x removable and hot-swappable 2.5 inch U.2 SSD or SATA.
Blackmagic Cloud Dock 4 lets you share up to 4 independent 2.5 inch disks over a high speed 10G Ethernet network. Just plug in SATA HDDs and SSDs, or extreme performance U.2 disks for incredibly fast file reading and writing. You can also sync files globally using Dropbox and Google Drive sync and view all storage, connection and sync activity in real time on a display connected to the HDMI monitor port. Blackmagic Cloud Dock 4 has 4 10G Ethernet ports, an Ethernet over USB-C port and an internal power supply in a single rack unit making it highly portable network storage that’s perfect for high end film and television use.
4 x removable and hot-swappable 2.5 inch U.2 SSD or SATA.
4 x 10G BASE-T
1 x USB 3.0 (up to 5Gb/s). Supports Ethernet Over USB
1
USB-C or Ethernet for shared file access, configuration and software updates.
SMB
50 max.
Dropbox
Google Drive
Bring your own drive.
ExFAT (Windows/Mac) or HFS+ (Mac) file systems.
1080p50, 1080p59.94, 1080p60
Device Name, storage capacity and use, Cloud Sync status, User Activity, Hardware Status, storage map, network data rate graph.
LED bezel indicator lights around SSD media slots.
USB-C or Ethernet for configuration and software updates.
Blackmagic Cloud Setup Utility
Blackmagic Proxy Generator Lite
Internal software upgrade via Blackmagic Cloud Setup using USB-C port
Mac 12.0 Monterey,
Mac 13.0 Ventura or later.
Windows 10, 64-bit.
Windows 11.
Internal 100 - 240V AC 50/60Hz with IEC C14 mains input.
60W without SSDs.
0° to 40° C (32°to 104° F)
-20° to 60° C (-4° to 140° F)
0% to 90% non-condensing
Blackmagic Cloud Dock 4
Welcome wallet with QR code for software download
12 Month Limited Manufacturer’s Warranty.
