Platform: Windows Vista, Server 2008, Windows 7, Server 2008 R2, Windows 8, Server 2012, Windows 10 & Server 2016 (32-bit and 64-bit versions supported), Windows Server 2019. (Note: Windows XP and Server 2003 are not supported
Processor: 2GHz quad-core or better
Memory: 1GB minimum
Motherboard: PCIe socket, single lane or greater
Other: Sound card or motherboard sound port for monitoring
Specification
Tuning Range: Band III (174-240 MHz)
DAB Format: Mode 1
RF Input: BNC connector
PCIe Interface: Single lane PCIe 1.1
Number of Ensembles: Factory-configured for 1, 2, 3 or 4 ensembles (field-expandable for an additional fee)
Audio Format: 48kHz 16-bit stereo (other application sampling rates and bit depths supported through the Windows SRC) (24kHz and 32kHz services are internally up-converted to 48kHz)
Decoding Latency: 3 seconds
Equipment Type
PC-DAB: 1 DAB+ Ensemble PCIe Radio Capture Card
PC-DAB2: 2 DAB+ Ensemble PCIe Radio Capture Card
PC-DAB3: 3 DAB+ Ensemble PCIe Radio Capture Card
PC-DAB4: 4 DAB+ Ensemble PCIe Radio Capture Card
PC-DABUP: Radcap DAB+ 1 Ensemble Upgrade
Physical Specification
Dimensions (Raw): 14cm (L) x 12.5cm (H) x 2cm (D) 5.5" (L) x 4.9" (H) x 0.8" (D)
Dimensions (Boxed): 27cm (L) x 22.5cm (H) x 6cm (D) 10.6" (L) x 8.9" (H) x 2.4" (D)
